Elbow is a commonly used connection pipe fittings in water heating installation, Which is used to connect the corner of the pipeline and change the direction of the pipeline.
Because the elbow has good comprehensive performance, It is widely used in chemical industry, construction, water supply, drainage, petroleum, light and heavy industry, Refrigeration, health, water heating, fire fighting, power, aerospace, shipbuilding and other basic projects.
Product Name: Pipe elbow
Size: 1/2" up to 24" seamless, 8" up to 110" welded
Dimension Standard : ANSI B16.9, EN10253-4, DIN 2605, GOST 17375-2001, JIS B2313, MSS SP 75, etc. or customized
Wall Thickness: SCH5S, SCH10S, SCH10, SCH40S, STD, XS, SCH80S, XXS, SCH20, SCH30, SCH40, SCH60, SCH80, SCH160, XXS, cusomized, and etc.
Product Details
4 inch 90 degree threaded elbow pipe fitting sch 40
Elbow is a commonly used connection pipe fittings in water heating installation, Which is used to connect the corner of the pipeline and change the direction of the pipeline.
Because the elbow has good comprehensive performance, It is widely used in chemical industry, construction, water supply, drainage, petroleum, light and heavy industry, Refrigeration, health, water heating, fire fighting, power, aerospace, shipbuilding and other basic projects.
Related Parameters
Product Name | Pipe elbow |
Size | 1/2" up to 24" seamless, 8" up to 110" welded |
Dimension Standard | ANSI B16.9, EN10253-4, DIN 2605, GOST 17375-2001, JIS B2313, MSS SP 75, etc. or customized |
Wall Thickness | SCH5S, SCH10S, SCH10, SCH40S, STD, XS, SCH80S, XXS, SCH20, SCH30, SCH40, SCH60, SCH80, SCH160, XXS , cusomized, and etc. |
Degree | 30° 45° 60° 90° 180° customized, etc. |
Radius | LR/long radius/ R=1.5D, SR/Shrot radius/ R=1D, various radius: 3D, 4D, 5D, 6D, 7D, 10D, 20D etc. |
Connection End | |
Bevel end/ BE /buttweld | |
Surface | Pickled, sand blasting, rolling blast,brighten,matt polished,mirror polished,vanished,shinning |
Material | |
Stainless steel | A403 WP304/304L, A403 WP316/316L, A403 WP321, A403 WP310S, A403 WP347H, A403 WP316Ti, A403 WP317, 904L, 1.4301,1.4307,1.4401,1.4571, 1.4541, 254Mo and etc. |
Duplex stainless steel | UNS31803, SAF2205, UNS32205, UNS31500, UNS32750, UNS32760, 1.4462,1.4410,1.4501 and etc. |
Nickel alloy | inconel600, inconel625, inconel690, incoloy800, incoloy 825, incoloy 800H, C22, C-276, Monel400, Alloy20 etc. |
