    Product Details

    1D 1.5D grade 90 degree deg welding bend elbow connector 3A DIN SMS ISO DS carbon elbow pipe fittings

    The pipe elbow is installed between two pipes so that the fluid direction can be changed to 45 degrees.

    The 45 degree bend produces less friction and lower pressure than the 90 degree bend.

    Using a 90° elbow upstream of the pump inlet can distort the near current, resulting in velocity changes in space and time and cyclone, thus negatively affecting the performance of the pump and increasing maintenance requirements.

    The introduction of more elbows or bends into the 3-inch pipe, especially the 90-degree ones, will have a great impact on the liquid pressure while reducing its flow.



    elbow14

    Related Parameters

    Technical specifications



    Type

     Pipe Elbow

    Standard

    API5L , ASTM A106 Gr.B, ASTM A53 Gr.B,ANSI A210-1996, ANSI B36.10M-2004  , ASTM A1020-2002,ASTM A179-1990 ,BS 3059-2,DIN 17175 ,DIN 1630 ,DIN 2448

    Size

     1/4" to 14"

    Wall Tickness

    SCH10, SCH20, SCH30, STD, SCH40, SCH60, SCH80, SCH100 SCH120, SCH160, XS, XXS

    Material

     GR.B,ST52, ST35, ST42, ST45,X42, X46, X52, X56, X60, X65, X70,SS304, SS316 etc.

    Surface

    black paint, varnish, oil, galvanized, anti corrosion coatings.

    Packing

    Loose package; Packaged in bundles(2Ton Max);  bundled pipes with two slings at the both end for easy loading and discharging; End with Plastic caps; wooden cases.

    Application liquid delivery; Structure pipe; High and low pressure Boiler tube; Seamless steel tubes for petroleum cracking; oil pipe; gas pipe.

    Product Details

    elbow27
    elbow27
    elbow26
    elbow26
    elbow24
    elbow24
